5MP Camera Module OV5640 Fill In Led Light
|
Module Number |
SNS-USB5640AF-V1.0 |
Sensor |
1/4"Omnivision OV5640 |
|
Resolution |
5MP (2592*1944) |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Auto Focus |
|
Interface |
USB2.0 |
Feature |
HD |
Products Description
The OV5640 USB camera module provides 5MP HD resolution (2592x1944) with clear and detailed images. It features fast autofocus to keep images sharp at different distances.
Its ultra-thin 62x9mm strip design makes it easy to integrate into narrow spaces, such as laptops, advertising machines, or embedded devices. Optional LED fill light ensures good imaging in low-light conditions, and a built-in microphone can capture audio when needed.
With USB2.0 plug-and-play interface, this module is easy to use and driver-free, making it versatile for various HD imaging applications.
Highlights
5MP HD resolution: Clear images with detailed capture.
Fast autofocus: Sharp images at different distances.
Ultra-thin strip design: Fits narrow spaces easily.
Optional LED light and microphone: Flexible for different environments.
Driver-free USB2.0 interface: Easy to connect and use.
Product Structure
Specification
|
Model No |
SNS-USB5640AF-V1.0 |
|
Pixel Size |
1.4μm x 1.4μm |
|
Effective Pixels |
HD 2592(H)X1944(V) |
|
Image Sensor |
1/4" |
|
AEC/AWB/AGC |
Supported |
|
Lens View |
FOV60°(Optional),F/N(Optional) |
|
Interface |
USB BUS POWER 5P-1.0mm |
|
Operating Voltage |
DC5V |
|
Working Current |
120mA~220mA |
|
Dimension |
62X9mm |
|
Cable Length |
1m/1.5m |
