USB Camera Module
The USB Camera Module is an imaging device connected via a Universal Serial Bus (USB) interface. It is a compact and powerful imaging solution with the best feature of plug-and-play wide compatibility, which can be directly and seamlessly connected to existing embedded vision devices or systems.
Founded in 2009, as a leading camera module manufacturer in China, Muchvision has been adhering to the concept of "innovation-driven development" for many years, and is committed to providing customers with one-stop services from design, development to manufacturing and OEM/ODM customized CMOS image processing solutions.
Why Choose Us
Quality Control
A strict quality control system has been implemented within the factory, and every step of the process, from purchasing to final product shipment, is meticulously inspected and tested to ensure that every product meets international standards.
Professional team
We have a team of senior engineers and technicians who know every detail of the camera modules to ensure that the quality of our products is always at the forefront of the industry.
Rich experience
With more than 10 years of professional manufacturing experience, our factory specializes in producing all kinds of camera modules.
Excellent Customization Capabilities
With many years of experience, Muchvision's tailored solution will give you the most suitable camera module.
USB Camera Module Specifications
|
Pixel |
2.3 Mega Pixel |
|
Sensor |
1/2.6'' On Semiconductor AR0234 Sensor |
|
Frame Rate |
60fps |
|
Pixel Size |
3.0μm*3.0μm |
|
Output Format |
YUY2/MJPG |
|
Shutter Type |
Global Shutter |
|
Chroma |
Color image |
|
Focus |
Fixed focus |
|
Dynamic range |
TDB |
|
Responsivity |
56 Ke-/luxsec |
|
Interface type |
USB2.0 |
|
Adjustable parameter |
Brightness/Contrast/Color saturation/Hue/Definition |
|
Gamma/White balance/Exposure |
|
|
Lens |
Focal length:2.8mm |
|
FOV: 177° small distortion |
|
|
Thread Size |
M12*P0.5 |
|
Working Current |
MAX 200mA |
|
Voltage |
DC 5V |
|
Auto Exposure Control |
Support |
|
Auto White Balance |
Support |
|
Auto Gain Control |
Support |
|
Interface |
USB2.0 |
|
Operating Temp |
-4°F~158°F (-20°C~+70°C) |
|
PCB Size |
32*32MM(Hole pitch compatible with 28x28mm) |
|
Cable Length |
Default 1.5M |
|
TTL |
22.2MM |
|
Support OS |
Windows XP(SP2,SP3),Vista ,7,8,10,Linux or OS with UVC driver |
Global Shutter: Shoot high-speed moving objects in crisp sharp images. Avoid the rolling artifacts to get a much more accurate complete picture than the rolling shutter cameras. Reserved external trigger ports, support trigger via external signal.
Resolution: 2.3MP @60fps;
Wide Angle Lens: The 1080p global shutter camera module has a wide view of angle,the d=177degree.
Plug&Play: UVC-compliant, just connect the camera to PC computer, laptop, Android device or Raspberry Pi with the USB cable without extra drivers to be installed.
Applications
Temperature Measurement
The camera adds the temperature measurement function on the technology of face recognition to replace manual operation during the epidemic prevention and control period.
financial and security systems
The camera module is very small in size, but powerful in function. Banks’ financial and security systems have surveillance cameras in hidden corners
Monitoring System
Installing a camera at home to watch the pets, checking the family members at any time, we can take care of everything at home easily even if we are outside, realizing the remote operation of smart home and use the two-way intercom.
Barcode Scanner
The application of the camera module in supermarkets and catering terminals enables customers to scan the barcode of commodities by themselves and pay for consumption by scanning the barcode, which reduces the waiting time of customers and saves labor costs camera module in developing.
USB Camera Module Customization Process
1. You can provide drawings or samples, as well as request documentation and developed by our engineering staff.
2. Communication or Meeting.
3. We will communicate with you in detail to determine somewhat product you need and try to set the most suitable product for you according to your needs.
4. Sample Development.
5. Determine the details of the development sample and the delivery time. Communicate at any time to ensure smooth progress.
6. Sample Testing.
7. Test and age on your application, feedback test results, no need to modify, mass production.
Our Certificates
FAQ
As one of the leading USB camera module manufacturers and suppliers in China, we warmly welcome you to buy high-grade USB camera module from our factory. All customized products are with high quality and competitive price.
