Full HD USB3.0 Camera Module 1080P 120FPS

Full HD USB3.0 Camera Module 1080P 120FPS

Module Number:SNS-DZ1224-02-V1.0
Sensor:1/2.6 Inch Sensor
Resolution:1920 × 1080
Dimension:(customizable)

Model:Signal SNS-DZ1224-02-V1.0
Image Sensor Size:1/2.6” inch
Effective Pixels:1920 × 1080
Pixel Size:3.0 µm × 3.0 µm
Send Inquiry
Add To Inquiry
Description
Technical Parameters

Module Number

SNS-DZ1224-02-V1.0

Sensor

1/2.6 Inch Sensor

Resolution

1920 × 1080

Dimension

(customizable)

Lens FOV

85°(optional)

Focus Type

FF

Interface

USB3.0

Feature

HD,120fps



Products Description



This high definition USB3.0 CMOS camera module is designed for video conferencing, online streaming, and security applications. It features a 1/2.6 inch sensor and provides 1080P video at 120fps, delivering smooth, high-quality visuals.

The global shutter sensor reduces motion blur, while advanced image processing ensures clear, realistic colors even in low light conditions.

With a USB3.0 interface supporting 3Gbps, it enables uncompressed, real-time video transfer. Video formats include MJPG and YUY2, with still images in JPG or BMP and dynamic recording in AVI or MP4.



Highlights



1080P Full HD video at 120fps with 1/2.6 inch CMOS sensor

Global shutter for smooth, blur-free video

USB3.0 plug-and-play interface with 3Gbps speed

Enhanced low light performance and wide dynamic range



parameter



Item

Specification

Model

Signal SNS-DZ1224-02-V1.0

Image Sensor Size

1/2.6" inch

Effective Pixels

1920 × 1080

Pixel Size

3.0 µm × 3.0 µm

Image Sensor Data Output

Raw Bayer 10 bits

Video Output Format

MJPG / YUY2

Maximum Resolution & Frame Rates

- 1920 × 1200 → MJPG 120 FPS / YUY2 60 FPS
- 1920 × 1080 → MJPG 120 FPS / YUY2 60 FPS
- 1600 × 1200 → MJPG 120 FPS / YUY2 60 FPS
- 1280 × 960 → MJPG 120 FPS / YUY2 120 FPS
- 1280 × 720 → MJPG 120 FPS / YUY2 120 FPS
- 640 × 480 → MJPG 120 FPS / YUY2 120 FPS

SNR (max)

38 dB

Dynamic Range

71.4 dB

Minimum Illumination

TBD

Digital Interface

USB3.0 (Type-B)

Transfer Rates

3 Gbps

Power Requirements

5V ± 5%

Storage Temperature

-40℃ ~ 70℃

Operating Temperature

-30℃ ~ 60℃

Power Consumption

NO LED / IR-LED / PCB printing ink black

Operating System Support

Windows XP / Vista / 7 / 8.1 / 10 / Mac / Android / Linux 2.6.2 (UVC supported)

Effective Focal Length (EFL)

3.2 mm ±5%

F/NO (Aperture)

2.2 ±5%

Field of View (FOV)

D: 92° / H: 82° / V: 57° ±3°

Optical Distortion

< -0.1%

Lens Construction

4G2P + IR

Lens View (Default Lens)

M12 × P0.5

Focus Type

Fixed focus

Shooting Distance

60 cm ~ ∞
