2mp Camera Module
Founded in 2009, as a leading camera module manufacturer in China, Muchvision has been adhering to the concept of "innovation-driven development" for many years, and is committed to providing customers with one-stop services from design, development to manufacturing and OEM/ODM customized CMOS image processing solutions.
Why Choose Us
Quality Control
A strict quality control system has been implemented within the factory, and every step of the process, from purchasing to final product shipment, is meticulously inspected and tested to ensure that every product meets international standards.
Professional team
We have a team of senior engineers and technicians who know every detail of the camera modules to ensure that the quality of our products is always at the forefront of the industry.
Rich experience
With more than 10 years of professional manufacturing experience, our factory specializes in producing all kinds of camera modules.
Excellent Customization Capabilities
With many years of experience, Muchvision's tailored solution will give you the most suitable camera module.
2mp Camera Module Specifications
|
Sensor |
Cmos IMX462 |
|
Shutter Type |
Electronic Rolling Shutter |
|
Focus |
Manually |
|
Compression format |
MJPEG/YUY2 |
|
Resolution & frame |
1920x1080 MJPEG @30fps 1280x720 MJPEG @30fps 640x480 MJPEG @30fps YUY2 @30fps 320x240 MJPEG @30fps YUY2 @30fps |
|
Interface |
USB2.0 |
|
Star Light |
Working Perfect both in light and low light condition |
|
Minimum Illumination |
0.0001 LUX |
|
Lens Parameter |
Starlight 4MM 85degree Lens |
|
Lens Aperture |
F=1.0 |
|
Voltage |
DC5V |
|
Night Vision |
Optional |
|
IR-CUT Filter(IR Filter) |
Default at 650nm,custom options at 850 or 940nm |
|
IR Illumination |
Default not available,can be customized upon request |
|
USB Video Class(UVC) |
Support |
|
OTG |
Support |
|
Auto Exposure AEC |
Support |
|
Auto white blance AEB |
Support |
|
Adjustable parameters |
Brightness/Contrast/Color saturation/Definition/Gamma/WB |
|
Dimension |
38x38mm |
|
Operating Temperature |
-20 to 70°C |
|
Support OS |
Windows,Linux,Mac,Android |
1. This 2MP mini Compact Camera Module is based on the 1/4″ OV2640 SOC sensor, which has an on-chip ISP, so as to do auto-exposure, auto-white balance to represent a nice image.
2. DVP interface standards for digital video port, friendly to most of the low-end ARM and RISC microcontrollers like STM32, ESP32.
3. The function of the hardware JPEG encoder, it off-loads the processing power and reduces memory footprint usage from the microcontrollers.
4. Resolution: 1600 x 1200 (UXGA); Maximum Image Transfer Rate: 15fps@1600×1200, 30fps@SVGA, 60fps@CIF; Output Format: YUV/RGB/Raw RGB Data
5. Lens SPEC: Stock lens; 52 degree (D) field of view angle; Integral 650 IR filter, visible light only; Lower than 1% distortion.
Applications
Smartphones
The application of camera modules in smartphones is the most common and significant. Through camera modules of different types and specifications, mobile phone users can take high-resolution photos and videos, and realize functions such as video calls, face recognition, and augmented reality.
Field of security monitoring
The application of camera modules in the field of security monitoring is also becoming more and more extensive. From home security cameras to monitoring systems in commercial buildings, camera modules provide effective security measures through real-time monitoring and recording functions.
Car dashcams and autonomous driving systems
In addition, with the development of autonomous driving technology, camera modules also play a key role in car dashcams and autonomous driving systems.
Medical field
In the medical field, camera modules are also used in medical imaging equipment and telemedicine systems. For example, endoscopes and surgical camera modules can provide high-resolution images at the microscopic level to help doctors make accurate diagnoses and surgical operations.
Shipping
We will pack and send your goods within 2-3 working days after we confirmed your payment. For quickly packing and sending, please let us know if you finished the payment.
We usually ship by DHL, UPS, TNT, FedEx, Aramex or EMS. It usually takes 3-7 days to arrive. Air cargo and sea shipping are aslo optional.
We will inform you the lead time if we have to purchase from manufactory.
Tracking number will be shared with you when we got it from the logistics company.
We are not responsible for any accidents, delays or other issues that are the responsibility of shipping service.
We need your shipping information including your name, address and phone number for shipping your parcel.
Our Services
|
Quick Response |
Within 24hours you can get a reply. |
|
Sample |
Sample is available,it will be send 2-3day after your paid sample charge and shiping cost. |
|
Shipping method |
By sea,by air,by express(DHL,UPS,FEDEX,TNT,HK post,China post,EMS,SF etc) |
|
OEM&ODM |
OEM desgin,OEM color,OEM packing,ODM are highly welcome. |
|
Trade Terms |
EXW,FOB,CIF or as per your request. |
|
QC |
Each product will be 100% inspected before shiping. |
|
After-Service |
Responsible and effective |
|
Warranty |
12 months. |
Our Certificates
FAQ
As one of the leading 2mp camera module manufacturers and suppliers in China, we warmly welcome you to buy high-grade 2mp camera module from our factory. All customized products are with high quality and competitive price.
2MP OV2312 MIPI Interface Camera Module, SP250 2mp Camera Module Low Power
