USB2.0 Global Shutter Camera Module
Your Professional USB2.0 Global Shutter Camera Module Supplier
Muchvision Technology Co., Ltd. was founded in 2009, since its inception, we have always adhered to the "innovation-driven development" concept, is committed to growing into the world's leading vision solutions provider.Muchvision initially for the major cell phone manufacturers for cell phone camera module OEM, with the strength of the excellent strength and excellent team support, quickly became the leading cell phone camera module manufacturers.
Why Choose Us
Quality Control
A strict quality control system has been implemented within the factory, and every step of the process, from purchasing to final product shipment, is meticulously inspected and tested to ensure that every product meets international standards.
Professional Team
With more than 10 years of professional manufacturing experience, our factory specializes in producing all kinds of camera modules. We have a team of senior engineers and technicians who know every detail of the camera modules to ensure that the quality of our products is always at the forefront of the industry.
Excellent Customization Capabilities
With many years of experience, Muchvision's tailored solution will give you the most suitable camera module. From design to manufacturing, trust muchvision to provide you with unmatched precision and expertise.
Qualifications and Certifications
ISO 9001 Quality Management System Certification: Muchvision strictly adheres to the ISO 9001 standard to ensure that the quality of our products and services meets international standards.
CE certification: Our camera modules comply with the safety, health and environmental requirements of the European market and have the CE mark for free circulation within the European Economic Area.
USB2.0 Global Shutter Camera Module Specifications
|
Model No |
SNS-2MP-OG02B10-V1.0 |
|
Sensor |
1/2.9'' Omnivision OG02B10 |
|
Pixel |
2 Mega Pixel |
|
Most effective pixels |
1600(H) x 1200(V) |
|
Pixel Size |
3.0µm x 3.0µm |
|
Chroma |
COLOR |
|
Compression format |
MJPG / YUY2 |
|
Resolution & Frame rate |
See above |
|
Shutter Type |
Global shutter |
|
Focus type |
Fixed Focus/Manually Adjustable |
|
Clock Frequency |
6 to 27 MHz |
|
Chief Ray Angle (CRA) |
15° |
|
Microphone |
Optional |
|
Interface type |
USB 2.0 high speed |
|
Adjustable parameter |
Brightness/Contrast/Color saturation/Hue/Definition/Gamma |
|
Lens |
Lens Structure: 6G |
|
Lens Size: 1/2.5 inch |
|
|
H FOV: 90° |
|
|
Thread Size: M12*P0.5 |
|
|
Audio frequency |
Optional |
|
Power supply |
USB BUS POWER |
|
Power consumption |
DC 5V, <200mA |
|
Main chip |
DSP/SENSOR/FLASH |
|
Auto Exposure Control (AEC) |
Support |
|
Auto White Balance (AEB) |
Support |
|
Auto Gain Control (AGC) |
Support |
|
Dimension |
38mmx38mm (compatible with 32mmx32mm) |
|
Storage temperature |
-20°C to 75°C |
|
Operating temperature |
0°C to 60°C |
|
USB cable length |
Default |
|
Support OS |
WinXP/Vista/Win7/Win8/Win10 |
Features
Global Shutter for Fast Action Powered by the selected global shutter sensor, this camera uses a global shutter to accurately capture fast-moving scenes without motion blur—ideal for robotics, automation, and high-speed imaging.
Onboard ISP for Image Tuning Integrated image signal processor supports real-time control of brightness, contrast, saturation, white balance (auto/manual), gain, and exposure (auto/manual), allowing for precise image adjustments in diverse environments.
Designed for Edge AI Applications Engineered for edge deployment, this camera delivers reliable performance across a wide range of AI vision applications, from object detection to smart inspection systems.
High-Resolution Imaging Delivers 2.3MP (1920×1200) resolution, producing crisp and detailed images for demanding machine vision and quality control tasks.
[Humanoid] Various of humanoid robotics applications
[Machine Vision Inspection] Detecting defects, labels, or alignment in manufacturing lines
[Robotic Navigation] Visual guidance for mobile robots and AGVs (Automated Guided Vehicles)
[Barcode/QR Code Scanning] High-speed decoding in logistics and packaging systems
[Pick-and-Place Systems] Real-time object tracking for automation arms
[Other Robotics related applications]
