USB3.0 OV7251 48p Global Shutter Camera Module
|
Module Number |
SNS-DZ1030-V1.0 |
Sensor |
1/7.5" Omnivision OV7251 |
|
Resolution |
0.3MP 640(H) X 480(V) |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Fixed Focus |
|
Interface |
USB2.0 |
Feature |
Global Shutter |
Products Description
The USB3.0 Camera Module SNS-DZ1030-V1.0 integrates a 1/7.5-inch OmniVision OV7251 CMOS global shutter sensor, offering monochrome imaging with excellent contrast and edge sharpness. Its advanced global shutter technology ensures 99.96% shutter efficiency, completely eliminating motion blur and the "jello effect," making it ideal for high-speed object tracking, industrial inspection, and SLAM applications.
With ultra-high frame rate capabilities:
640x480 (VGA): 120FPS
320x240 (QVGA) BIN mode: 180FPS
160x120 (QQQVGA) BIN/SKIP mode: 360FPS
The module outputs high-quality black-and-white images even under low-light conditions. Its USB3.0 high-speed interface ensures fast, stable data transmission and broad compatibility with Windows, Linux, macOS, and Android systems. Compact and customizable, it suits various precision vision applications.
Highlights
OmniVision OV7251 global shutter sensor
0.3MP (640x480) monochrome images
Ultra-high frame rates: VGA@120FPS, QVGA@180FPS, QQQVGA@360FPS
USB3.0 interface, high-speed plug-and-play
Industry-leading 99.96% shutter efficiency
Ideal for machine vision, industrial inspection, and SLAM
Specification
|
Model No |
SNS-DZ1030-V1.0 |
|
Sensor |
1/7.5'' Omnivision OV7251 |
|
Pixel |
0.3 Mega Pixel |
|
Most effective pixels |
640(H) x 480(V), 320(H) x 240(V) |
|
Pixel Size |
3.0µm x 3.0µm |
|
Image area |
1968um(H) x 1488um (V) |
|
Compression format |
MJPG |
|
Resolution & Frame rate |
640x480@120fps; 320x240@200fps |
|
Shutter Type |
Global Shutter |
|
CFA (Chroma) |
Mono, Black/White |
|
Focus type |
Fixed focus |
|
S/N ratio |
38dB |
|
Dynamic range |
69.6dB |
|
Sensitivity |
10800mV / lux-sec |
|
Interface type |
USB2.0 high speed |
|
|
Brightness/Contrast/Color saturation/Hue/Definition//White balance |
|
Lens |
Focal length: 3.6mm |
|
Lens Size: 1/4 inch |
|
|
FOV: 160° |
|
|
Thread Size: M12*P0.5 |
|
|
Audio frequency |
Optional |
|
Power supply |
USB BUS POWER |
|
Power consumption |
DC 5V, 120mW |
|
Main chip |
DSP/SENSOR/FLASH |
|
Auto Exposure Control (AEC) |
Support |
|
Auto White Balance (AEB) |
Support |
|
Auto Gain Control (AGC) |
Support |
|
Storage temperature |
-30°C to 70°C |
|
Operating temperature |
0°C to 60°C |
|
USB cable length |
Default |
|
Support OS |
WinXP/Vista/Win7/Win8/Win10 |
