Low Light Camera Module
Low light camera modules are camera modules designed for capturing images in low light environments. They can adapt to lighting conditions as low as 1 lux or even 0.5 lux. They perform very well in high sensitivity, high quantum efficiency, and infrared spectrum imaging. This makes them very popular in low light vision fields such as medical microscopy and smart monitoring.
Founded in 2009, as a leading camera module manufacturer in China, Muchvision has been adhering to the concept of "innovation-driven development" for many years, and is committed to providing customers with one-stop services from design, development to manufacturing and OEM/ODM customized CMOS image processing solutions.
Why Choose Us
Quality Control
A strict quality control system has been implemented within the factory, and every step of the process, from purchasing to final product shipment, is meticulously inspected and tested to ensure that every product meets international standards.
Professional team
We have a team of senior engineers and technicians who know every detail of the camera modules to ensure that the quality of our products is always at the forefront of the industry.
Rich experience
With more than 10 years of professional manufacturing experience, our factory specializes in producing all kinds of camera modules.
Excellent Customization Capabilities
With many years of experience, Muchvision's tailored solution will give you the most suitable camera module.
Low Light Camera Module Specifications
|
Sensor |
IMX323 |
|
Lens Size |
1/2.9" |
|
Maximum Pixels |
2 mega |
|
Maximum Effective Resolution |
2001 (H) × 1121 (V) approx. 2.24 M pixels |
|
Data Format |
YUY2/MJPG/H.264 |
|
Pixel Size |
2.8×2.8(µm)h(v) |
|
Dynamic Range |
Colorful: 0.01 Lux@F1.2, black & white: 0.005 Lux@F1.2 |
|
Lens |
FOV :D=130°,H=101°,V=65° |
|
Optical length :21.39MM |
|
|
Lens construction:4G |
|
|
Mount :M12*P0.5mm |
|
|
Focusing |
Fixed focus |
|
Frame Rate |
30fps |
|
Auto Control |
Saturation,Contrast, Acutance,White balance,Exposure |
|
Audio |
High quality digital MIC, single or dual channel is optional |
|
Voltage |
DC 5V |
|
Working Current |
MAX 300mA |
|
USB Connector |
USB2.0 |
|
Storage Temperature |
-20ºC to +70ºC |
|
Working Temperature |
Change with environmental temperature |
|
System Compatibility |
1,Windows XP(SP2,SP3),Vista ,7,8,10 |
|
2,Linux or OS with UVC driver |
HD Resolution and Low Light: This camera adopts the 2MP IMX291 Color CMOS sensor with an 80DB wide dynamic range, can capture the minimum illumination 0.001Lux.
Wide Angle: High quality 100 degree wide view angle (diagonal) M12 lens with IR filter.
Capture Video with Audio: High frame rates, H.264 30fps@1920x1080; MJPG 30fps@1920x1080; YUY2 30fps@640x 480; Audio, single microphone (optional dual channel).
Plug&Play: UVC-compliant, support Windows XP/7/8/10, Linux, and Mac OS, just connect the camera to PC, laptop or Raspberry Pi with the USB cable without extra drivers to be installed.
The Composition of the Low Light Camera Module
Lens
The lens is a vital part of the camera module. used for imagery. A key aspect in determining picture quality is the quality of the lens.
Infrared filter
The sensor on the camera can accept a wider range of light wavelengths than the human eye, so the infrared filter can filter out those invisible rays.
There are two types of sensors
CCD (Charge Coupled Device) and CMOS (Complementary Metal Oxide Semiconductor). CCD has better sensitivity, so it can take better pictures.
Bracket
A structure, usually plastic, into which all components fit.
VCM
The component is embedded in the holder. It is the lens used to adjust the focal length of the lens.
Sensor
Another key component is the camera module. It is used to receive the picture produced by the lens.
Applications
Smart traffic - Smart traffic systems use cameras for tasks such as ALPR (Automatic License Plate Recognition), vehicle counting, and people analytics.
Smart surveillance - Any kind of surveillance system that has to operate in low light needs an ultra-low light camera. We earlier spoke about why a parking lot management system (which is a type of smart surveillance) needs a high sensitivity camera.
Medical microscopes - Certain types of microscopic applications (e.g. dark field microscopy) use the NIR spectrum to accurately analyze the specimen.
Patrol robots - Patrol robots automate surveillance by moving around the premises like a human. Since they have the requirement to operate 24/7, the cameras embedded in them require good low light capabilities.
We ships all orders via UPS Ground or USPS Priority Mail. If you prefer FedEx or another delivery agent - please contact us prior to purchase to confirm we can provide for your request.Orders are typically shipped within 1 day business day. Orders placed after 2PM EST, or over a weekend or holiday, are processed on the next business day
Our Certificates
FAQ
As one of the leading low light camera module manufacturers and suppliers in China, we warmly welcome you to buy high-grade low light camera module from our factory. All customized products are with high quality and competitive price.
