120FPS WDR Night Vision Camera Module IMX290
|
Module Number |
SNS-2MP-IMX290-V1.0 |
Sensor |
1/2.8" SONY IMX290 |
|
Resolution |
2MP 1920x1080 |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Fixed Focus |
|
Interface |
USB2.0 |
Feature |
Night Vision |
Products Description
This USB camera module features a 1/2.8-inch SONY IMX290 STARVIS™ CMOS sensor, delivering 2MP (1920x1080) Full HD images.
The module provides starlight-level night vision, capturing clear, low-noise images even in extremely low-light conditions. Its WDR (Wide Dynamic Range) functionality ensures balanced exposure in both bright and dark areas, producing high-quality images under complex lighting scenarios.
The camera supports multiple resolutions, including 1920x1080, 1280x960, 1280x720, 800x600, 640x480, and 320x240, achieving up to 60FPS at all resolutions for smooth real-time video streaming.
With a 120° field of view and USB2.0 interface, this module is UVC compatible and supports plug-and-play integration. It is ideal for security surveillance, industrial monitoring, factory automation, and other applications requiring high-performance imaging in low-light environments.
Highlights
SONY IMX290 STARVIS™ CMOS sensor.
2MP (1920x1080) Full HD resolution.
Excellent starlight-level low-light performance (night vision capability).
Supports WDR (Wide Dynamic Range).
Achieves 60FPS at all resolutions.
USB 2.0 interface, UVC compatible, plug-and-play.
Specification
|
Model No |
SNS-2MP-IMX290-V1.0 |
|
Sensor |
1/2.8'' SONY IMX290 CMOS |
|
Pixel |
2 Mega Pixel |
|
Most effective pixels |
1920(H) x 1080(V) |
|
Pixel Size |
2.9µm x 2.9µm |
|
Image area |
1937(H) x 1097(V) |
|
Compression format |
MJPEG / YUV2/H.264 |
|
Resolution & Frame rate |
1920 x1080 @ 60fps 1280x960 @60fps 1280x720 @ 60fps 800x600 @ 60fps 640x480 @ 60 fps 320x240 @ 60fps |
|
Shutter Type |
Electronic rolling shutter |
|
Focus type |
Fixed focus/Manually adjustable |
|
S/N ratio |
52dB |
|
Dynamic range |
72dB |
|
Sensitivity |
7757 mV / lux-sec |
|
Interface type |
USB2.0 and SPI |
|
Adjustable parameter |
Brightness |
|
Lens |
Optical length: 18.6mm |
|
F/NO: 2.4 |
|
|
FOV: D=120° |
|
|
Thread Size: M12*P0.5 |
|
|
Audio frequency |
Optional |
|
Power supply |
USB BUS POWER |
|
Power consumption |
DC 5V, 260mW |
|
Main chip |
DSP/SENSOR/FLASH |
|
Auto Exposure Control (AEC) |
NOT Support |
|
Auto White Balance (AEB) |
NOT Support |
|
Auto Gain Control (AGC) |
NOT Support |
|
Dimension |
38mm x 38mm |
|
Storage temperature |
-20°C to 70°C |
|
Operating temperature |
0°C to 60°C |
|
USB cable length |
Default |
|
Support OS |
WinXP/Vista/Win7/Win8/Win10 |
