Global Shutter Camera Module
Founded in 2009, as a leading camera module manufacturer in China, Muchvision has been adhering to the concept of "innovation-driven development" for many years, and is committed to providing customers with one-stop services from design, development to manufacturing and OEM/ODM customized CMOS image processing solutions.
Why Choose Us
Quality Control
A strict quality control system has been implemented within the factory, and every step of the process, from purchasing to final product shipment, is meticulously inspected and tested to ensure that every product meets international standards.
Professional team
We have a team of senior engineers and technicians who know every detail of the camera modules to ensure that the quality of our products is always at the forefront of the industry.
Rich experience
With more than 10 years of professional manufacturing experience, our factory specializes in producing all kinds of camera modules.
Excellent Customization Capabilities
With many years of experience, Muchvision's tailored solution will give you the most suitable camera module.
Global Shutter Camera Module Specifications
|
Max Resolution |
1280*720P |
|
Sensor |
1/4" OV9281 |
|
Frame Rate |
MJPG 60fps@1280 x 800/720P/800 x 600/640 x 480/320 x 240, 60fps@1280 x 800/800 x 600/640 x 480/320 x 240; YUY2 10fps@1280 x800/1280 x 720. |
|
Pixel Size |
3.0μm*3.0μm |
|
Output Format |
YUY2/MJPG |
|
Lens |
|
|
Focus |
Fixed focus |
|
FOV |
D=105° H=99° |
|
Lens Mount |
M12 * P0.5mm |
|
Focusing Range |
3.3ft (1M) to infinity |
|
Power |
|
|
Working Current |
MAX 200mA |
|
Voltage |
DC 5V |
|
Physical |
|
|
Interface |
USB2.0 |
|
Storage Temperature |
-20ºC to +70ºC |
|
Operating Temp |
-4°F~158°F (-20°C~+70°C) |
|
PCB Size |
32*32MM(Hole pitch compatible with 28x28mm) |
|
Cable Length |
3.3ft (1M) |
|
TTL |
22.7MM |
|
Functionality and Compatibility |
|
|
Adjustable parameter |
Exposure/ White balance |
|
System Compatibility |
Windows XP(SP2,SP3),Vista ,7,8,10,Linux or OS with UVC driver |
High resolution: 2MP resolution provides high definition images.
Compact design: Measuring only 38x38x10.2 mm, suitable for small devices.
High-speed capture: Supports 120 frames per second to ensure smooth video.
Temperature adaptability: Wide operating temperature range (-20°C to 60°C), suitable for various application scenarios.
Main Components
IMX577 Y709A camera module: It can support taking 12MP HD photos and recording 4K@30FPS videos. Supports advanced multi-axis EIS anti-shake image stabilization using the ICM-40607 model gyroscope..
USB Type-C interface: Supports USB standard 5V power input to power the camera module and charge the battery, and the USB port can be connected to a computer to read files from a TF card directly and use it as a USB flash drive, as well as to use it as a PCCAM USB camera.
Micro HDMI interface: Adopt Micro HDMI interface output, can support up to 4K@30FPS video signal output.
Battery interface: Use battery power supply, the battery voltage is between 6.6V (low power shutdown) ~ 8.8V, recommended to use 7.4 ~ 7.7V high-voltage high-density lithium batteries.
Global shutter camera module and high frame rate make it suitable for applications such as automatic number plate recognition (anpr), autonomous mobile robots (amr), gesture recognition, robotic vision, drones, barcode scanner, factory automation, conveyor monitoring cameras, and traffic monitoring systems.
Global Shutter Camera Module Customization Process
Drawing Confirmation
Confirm with the customers of your module type, sensor type, size, interface and other settings, and we would send you a product drawing diagram to finalize the design. After the customers' confirmation, let us move forward.
Mass Production
During mass production, production and quality control of mass-produced products would be carried out, to be sure that customized R&D and production of the camera module can be completed with high quality and quantity since it meets the customer's requirements.
Quotation
Send the quotation according to the design level of your products.
Shipping
Start shipping and keep tracking the good's transportation throughout the process.
Sample Development
Determine the details of the development sample and the delivery time. Communicate at any time to ensure smooth progress. It usually would be completed within 15 days.
Sample Testing
Send the first sample for confirmation, and mass production would be started after confirmation.
Our Certificates
FAQ
As one of the leading global shutter camera module manufacturers and suppliers in China, we warmly welcome you to buy high-grade global shutter camera module from our factory. All customized products are with high quality and competitive price.
