Infrared USB Camera Module SONY IMX335 Starlight 1080P Full HD with WDR for Dashcams and In-Vehicle Surveillance Applications

Infrared USB Camera Module SONY IMX335 Starlight 1080P Full HD with WDR for Dashcams and In-Vehicle Surveillance Applications

$60.00 | 0 (Min.Order)

Product Details:
Place of Origin: Shenzhen,China
Brand Name: Muchvision
Certification: RoHS、CE、FCC 、ISO9001

Payment & Shipping Terms:
Minimum Order Quantity:3
Price:negotiable
Packaging Details:Tray+Anti-static bag in carton box
Delivery Time:2-3weeks
Payment Terms:T/T
Supply Ability:500000 pieces/month
Send Inquiry
Add To Cart
Description
Technical Parameters

Infrared USB Camera Module WDR IMX335 Starlight



Module Number

SNS-GM967M-V1.0

Sensor

1/2.8" IMX335

Resolution

1920(H)X1080(V)

Dimension

(customizable)

Lens FOV

85°(optional)

Focus Type

Fixed Focus

Interface

USB2.0

Feature

WDR



Products Description



This USB camera module features a SONY 1/2.8-inch IMX335 STARVIS™ 5MP sensor, outputting 1080P (1920x1080) Full HD video.



The module provides starlight-level night vision, capturing clear images in extremely low-light conditions. Its 180° ultra-wide panoramic field of view ensures broad coverage for dashcams and in-vehicle monitoring.



Equipped with advanced WDR technology, it handles high-contrast lighting scenarios effectively, such as bright sunlight and deep shadows. The module maintains consistent, detailed Full HD video streams at 1080P resolution.



It is suitable for dashcams, vehicle surveillance, and various low-light and high-contrast applications. The USB2.0 interface allows easy integration into multiple systems.



Highlights



Equipped with SONY 1/2.8" IMX335 STARVIS™ 5MP image sensor.

Optimized output of 1080P (1920x1080) full HD video.

Excellent starlight-level night vision function.

Supports WDR (Wide Dynamic Range) technology.



Specification



Sensor

1/2.8" IMX335

Pixel

5 Mega Pixel

Most effective pixels

1920(H)X1080(V)

Pixel Size

2.0μm x2.0μm

Compression format

MJPG / YUY2

Resolution

see above

Frame rate

see above

Shutter Type

Electronic rolling shutter

Focus type

Fixed focus

S/N ratio

TdB

Dynamic range

TdB

Interface type

USB2.0

Adjustable parameter

Brightness/Contrast/Color saturation/Hue/Definition/
Gamma/White balance/Exposure

Lens

Focal length: 3.6mm

FOV:D180° H180°V180°F/N(2.0)

Thread Size: M12*P0.5

Audio frequency

Support

microphone

Built-in

Power supply

USB BUS POWER

Power consumption

DC 5V, 200mA

Main chip

DSP/SENSOR/FLASH

Auto Exposure Control (AEC)

Support

Auto White Balance (AEB)

Support

Auto Gain Control (AGC)

Not Supported

Storage temperature

-20~80℃

Operating temperature

0~60℃

USB cable length

Default


Support OS

WinXP/Vista/Win7/Win8/Win10
Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later
Android 4.0 or above with UVC
