Starlight Night Vision USB Camera Module SC2210
|
Module Number |
SNS-GM1052-V1.0 |
Sensor |
1/1.8" |
|
Resolution |
1920(H)X1080(V) |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Fixed Focus |
|
Interface |
USB2.0 |
Feature |
WDR |
Products Description
This USB camera module features a 1/1.8-inch SC2210 black optical sensor, delivering 1080P (1920x1080) Full HD video.
It provides starlight-level night vision, capturing clear images in complete darkness. The module includes a 180° ultra-wide fisheye lens, minimizing monitoring blind spots and enhancing coverage for security and surveillance applications.
Equipped with WDR (Wide Dynamic Range) technology, it handles high-contrast lighting scenarios effectively, ensuring detailed images in both bright and shadowed areas. The large pixel size improves low-light performance and overall image clarity.
This module is suitable for security monitoring, video conferencing, environmental sensing, and other low-light applications. Its USB2.0 interface allows straightforward system integration.
Highlights
1/1.8-inch SC2210 black optical sensor.
Starlight-level night vision capability.
1920x1080 full HD resolution.
180° ultra-wide-angle fisheye lens.
Supports wide dynamic range (WDR).
Specification
|
Sensor |
1/1.8" |
|
Most effective pixels |
1920(H)X1080(V) |
|
Pixel Size |
4.0μm x 4.0μm |
|
Compression format |
MJPG / YUY2 |
|
Resolution |
see above |
|
Frame rate |
see above |
|
Shutter Type |
Electronic rolling shutter |
|
Focus type |
Fixed focus |
|
S/N ratio |
TdB |
|
Dynamic range |
TdB |
|
Interface type |
USB2.0 |
|
Adjustable parameter |
Brightness/Contrast/Color saturation/Hue/Definition/ |
|
Lens |
Focal length: 3.6mm |
|
FOV:D180° H180°V180°F/N(2.0) |
|
|
Thread Size: M12*P0.5 |
|
|
Audio frequency |
Support |
|
microphone |
Built-in |
|
Power supply |
USB BUS POWER |
|
Power consumption |
DC 5V, 200mA |
|
Main chip |
DSP/SENSOR/FLASH |
|
Auto Exposure Control (AEC) |
Support |
|
Auto White Balance (AEB) |
Support |
|
Auto Gain Control (AGC) |
Not Supported |
|
Storage temperature |
-20～80℃ |
|
Operating temperature |
0～60℃ |
|
USB cable length |
Default |
|
|
WinXP/Vista/Win7/Win8/Win10 |
