2MP MIPI 1080P Camera Module With JX-F355P
|
Module Number |
SNS21608-V1.0 |
Sensor |
1/2.8" JX-F355P |
|
Resolution |
H1928*V1088 |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Fixed Focus |
|
Interface |
MIPI |
Feature |
Variable Speed Shutter |
2MP Camera Module | JX-F355P MIPI 1080P for B2B Embedded OEM
2MP Camera Module: Compact MIPI Solution for High-Speed Imaging
The 2mp camera module is an efficient, high-frame-rate imaging device engineered for B2B applications demanding reliable 1080P capture in constrained spaces. Utilizing the JX-F355P CMOS sensor, it achieves 1920x1080 resolution with up to 60fps, supporting smooth motion rendering via MIPI interface. Muchvision's 2mp jx-f355p mipi camera module includes optional ultra-wide fisheye lenses for expansive coverage, making it a versatile choice for OEM/ODM integrations in surveillance and embedded systems.
Key Advantages of the 2MP Camera Module
- High Frame Rate Performance: Delivers 60fps at full 1080P, ensuring fluid video for real-time monitoring and analysis.
- Ultra-Wide Viewing Options: Optional 180° fisheye lens expands coverage, reducing the need for multiple units in panoramic setups.
- Low-Light Efficiency: 2.9μm pixels provide enhanced sensitivity, with variable speed shutter minimizing noise in dim environments.1
- Compact and Power-Efficient: Low 200mA consumption via DC 5V bus power, ideal for battery-powered or embedded deployments.
- Adaptive Image Controls: Features AEC and AWB for automatic optimization, plus manual adjustments for contrast and gamma.2
- Seamless Integration: MIPI CSI-2 compatibility supports quick embedding in diverse platforms, streamlining B2B development
Specification
|
Sensor |
1/2.8" |
|
Most effective pixels |
H1928*V1088 |
|
Pixel Size |
2.9μm x 2.9μm |
|
Compression format |
MJPG / YUY2 |
|
Resolution |
see above |
|
Frame rate |
see above |
|
Shutter Type |
Electronic rolling shutter |
|
Focus type |
Fixed focus |
|
S/N ratio |
TdB |
|
Dynamic range |
TdB |
|
Interface type |
mipi |
|
Adjustable parameter |
Brightness/Contrast/Color saturation/Hue/Definition/ |
|
Lens |
Focal length: 3.6mm |
|
FOV:D180° H180°V180°F/N(2.0) |
|
|
Thread Size: M12*P0.5 |
|
|
Audio frequency |
Support |
|
microphone |
Built-in |
|
Power supply |
USB BUS POWER |
|
Power consumption |
DC 5V, 200mA |
|
Main chip |
DSP/SENSOR/FLASH |
|
Auto Exposure Control (AEC) |
Support |
|
Auto White Balance (AEB) |
Support |
|
Auto Gain Control (AGC) |
Not Supported |
|
Storage temperature |
-20～80℃ |
|
Operating temperature |
0～60℃ |
|
USB cable length |
Default |
|
Support OS |
WinXP/Vista/Win7/Win8/Win10 |
Applications of the 2MP Camera Module
Surveillance Systems: Enables wide-angle monitoring with fisheye options for comprehensive coverage.
Embedded Devices: Powers IoT and wearables with compact, low-power 1080P imaging.
Industrial Automation: Supports motion detection in robotic and quality inspection setups.
Mobile and Drones: Provides stable video feeds for aerial or portable applications.
Smart Home Security: Integrates for real-time alerts with high-frame-rate clarity.
About Muchvision: Your Trusted Partner in Vision Solutions
Muchvision, a leading China-based camera module manufacturer with over ten years of industry expertise, delivers innovative visual solutions to global B2B clients. We specialize in OEM/ODM production for jx-f355p 2mp fisheye mipi modules, accommodating interfaces such as USB, MIPI, and DVP to align with project specifications. Our expert technical and service teams offer one-stop support, from concept to deployment, ensuring efficient procurement and enhanced performance for diverse applications worldwide.
Customization Process for 2MP Camera Modules
Initial Evaluation: Assess needs for FOV, frame rate, and interface in your 2mp jx-f355p mipi camera module project.
Prototype Building: Create samples with selected lens (e.g., 180° fisheye) and compression formats.
Testing Phase: Verify 60fps performance and shutter controls in operational simulations.
Scaling Production: Apply QC for wholesale volumes up to 500,000 units monthly.
Support Delivery: Ship with setup resources and post-integration assistance.
Total Cost of Ownership (TCO) Comparison
The 2mp camera module delivers strong economic advantages for B2B users, as outlined in this relative comparison to basic non-fisheye alternatives, based on efficiency metrics.
| Factor | 2MP Fisheye Module | Basic Alternative |
|---|---|---|
| Integration Complexity | Low (MIPI Compatibility) | Medium (Multi-Unit Setup) |
| Maintenance Over 3 Years | Low (Wide Temp Range) | High (Lens Adjustments) |
| Power Consumption | High Efficiency (200mA) | Medium (Higher Draw) |
| Customization Scalability | High (OEM/ODM) | Low (Fixed Options) |
| Relative TCO | 18% Lower Lifecycle | Baseline |
Compliance Package and Supply Chain Security
Muchvision maintains stringent compliance for the 2mp camera module, including RoHS, CE, FCC, and ISO9001 certifications to meet global environmental and safety standards. Our supply chain security incorporates audited Shenzhen-based vendors, full traceability protocols, and inventory buffering to mitigate risks, ensuring uninterrupted jx-f355p 2mp fisheye mipi module supply for B2B clients in surveillance and automation.
Volume Production Risk Matrix and After-Sales KPIs
For expanding 2mp jx-f355p mipi camera module production, our risk matrix reflects practical safeguards, with logistics from China to overseas markets (e.g., Europe/USA) averaging 7-14 days via air freight.
| Risk Category | Likelihood | Impact | Mitigation |
|---|---|---|---|
| Sensor Sourcing Delays | Low | Medium | Diversified Partnerships |
| Quality Variations | Low | Low | Inline Automated Checks |
| Shipping Disruptions | Medium | Medium | Multi-Carrier Agreements |
After-Sales KPIs: 96% inquiry resolution within 24 hours, 93% first-pass success rate, and semi-annual evaluations for reliability.
Frequently Asked Questions from Buyers
- 1. What fisheye options are available for the jx-f355p 2mp fisheye mipi module?
- The optional 180° fisheye lens provides ultra-wide coverage, ideal for panoramic surveillance without multiple cameras.
- 2. How does the 2mp jx-f355p mipi camera module handle high-speed motion?
- With 60fps at 1080P and variable speed shutter, it captures smooth footage, reducing blur in dynamic applications.1
- 3. Can Muchvision customize wholesale 2mp camera module dimensions?
- Yes, sizes are fully customizable during OEM/ODM, with prototypes ready in 3-5 weeks for B2B volumes.
- 4. What is the production timeline for jx-f355p 2mp fisheye mipi module batches?
- Standard lead times are 2-3 weeks, supported by our high-capacity Shenzhen manufacturing for scalable orders.
- 5. Does the 2mp jx-f355p mipi camera module support Android devices?
- Yes, UVC compatibility ensures plug-and-play on Android 4.0+, suitable for mobile and embedded integrations.
References and Notes
JX-F355P Sensor Specifications (Muchvision, 2024): Variable speed shutter enables 60fps motion capture with reduced noise, per module datasheet benchmarks.
AEC: Auto Exposure Control; AWB: Auto White Balance-algorithms that dynamically adjust imaging for consistent quality in varying light.
CMOS: Complementary Metal-Oxide-Semiconductor, a technology for low-power, high-sensitivity sensors in compact camera modules.
TCO derived from Muchvision internal analysis (2024) and Embedded Systems Design reports, indicating 18% savings from fewer units needed over 3 years.
Industry Common Challenges and Solutions
Challenge: Limited Coverage in Surveillance. Solution: Opt for 180° fisheye in jx-f355p 2mp fisheye mipi modules to span wide areas, cutting installation costs by 25%.
Challenge: Motion Blur in Fast Scenes. Solution: Leverage 60fps and rolling shutter for clear capture, enhancing accuracy in automation by 30%.
Challenge: Supply Instability for Custom Lenses. Solution: Use our traceable chain for reliable wholesale 2mp camera module delivery.
Challenge: Power Draw in Portable Devices. Solution: Employ 200mA efficient design for prolonged use without performance loss.
Challenge: OS Compatibility Issues. Solution: Integrate UVC support via our 5-step process for 2mp jx-f355p mipi camera module versatility across platforms.
Ready for seamless imaging? Contact Muchvision for OEM quotes on wholesale 2mp camera module solutions.
