48MP USB2.0 CMOS Sensor Module With Wide Field

Module Number

SNS-DZ1204-V1.0

Sensor

customizable

Resolution

1920 × 1080

Dimension

(customizable)

Lens FOV

85°(optional)

Focus Type

FF

Interface

USB2.0

Feature

low distortion

Item

Specification

Model

Signal SNS-GM48M-V1.0

Image Sensor Data Output

Raw Bayer 10 bits

Video Output Format

MJPG / YUY2

Maximum Resolution & Frame Rates (MJPG)

- 7968 × 5984 → 3 FPS
- 5696 × 4272 → 5 FPS
- 4608 × 3456 → 10 FPS
- 4160 × 3120 → 10 FPS
- 4000 × 3000 → 10 FPS
- 3840 × 2160 → 25 FPS
- 2592 × 1944 → 20 FPS
- 1920 × 1080 → 30 FPS
- 1600 × 1200 → 20 FPS
- 1280 × 720 → 30 FPS
- 800 × 600 → 20 FPS
- 640 × 480 → 20 FPS
- 320 × 240 → 20 FPS

Maximum Resolution & Frame Rates (YUY2)

- 3840 × 2160 → 1 FPS
- 2592 × 1944 → 2 FPS
- 1920 × 1080 → 5 FPS
- 1600 × 1200 → 5 FPS
- 1280 × 720 → 10 FPS
- 640 × 480 → 20 FPS
- 320 × 240 → 20 FPS

SNR (Max)

TBD

Dynamic Range

TBD

Minimum Illumination

TBD

Digital Interface

USB2.0

Transfer Rates

480 MB/s

Power Requirements

5V ±5%

Power Consumption

Max 800 mA

Storage Temperature

-40°C ~ 70°C

Operating Temperature

Max 85°C

Operating System Support

Windows XP / Vista / 7 / 8.1 / 10 / Mac / Android / Linux 2.6.2 (UVC supported)

Effective Focal Length (EFL)

3.24 mm ±5%

F/NO (Aperture)

2.2 ±5%

Field of View (FOV)

D: 80° / H: 68° / V: 54° ±3°

Optical Distortion

< -0.5%

Lens View (Default Lens)

M12 × P0.5

Focus Type

Fixed focus
