GC2083 Dual Lens 2MP Camera Module USB Interface
|
Module Number |
SNS-SM1118-V1.0 |
Sensor |
1/3'GC2083 CMOS |
|
Resolution |
H1920*V1080 |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Fixed Focus |
|
Interface |
USB |
Feature |
HD |
Products Description
The GC2083 Dual Lens 2MP Camera Module uses two 1/3" GalaxyCore GC2083 CMOS sensors to deliver 1920x1080 full HD resolution. Its dual-lens design captures images from two perspectives simultaneously, enabling flexible multi-angle imaging.
A built-in fill light enhances performance in low-light conditions, reducing shadows and improving visibility. This makes the module ideal for video conferencing, live streaming, and nighttime surveillance.
The module connects via USB 2.0 interface and is UVC compatible for plug-and-play across Windows, Linux, macOS, and Android platforms. Its compact design and low power consumption ensure reliable performance for embedded and consumer electronics.
Highlights
GalaxyCore 1/3" GC2083 CMOS sensors
2MP full HD 1080P resolution
Built-in fill light for low-light imaging
Dual lens design for multi-angle capture
USB 2.0 interface, UVC compatible, plug-and-play
Specification
|
Model No |
SNS-SM1118-V1.0 |
|
Sensor |
1/3'GC2083 CMOS |
|
Pixel |
2 Mega Pixel |
|
Most effective pixels |
H1920*V1080 |
|
Pixel Size |
2.7um x2.7um |
|
Image Area |
5808µm x 3288µm |
|
Compression format |
YUV2 / MJPG |
|
Resolution |
See above |
|
Frame rate |
See above |
|
Shutter Type |
Electronic rolling shutter |
|
Focus type |
Fixed focus |
|
S/N ratio |
TBDdB |
|
Dynamic range |
TBDdB |
|
Sensitivity |
3700 mV/lux-sec |
|
Interface type |
USB2.0 |
|
|
Brightness/Contrast/Color saturation/Hue/Definition/ |
|
Power supply requirement |
AVDD28: 2.7~3.3V(Typ.2.8V) |
|
DVDD18: 1.15~1.3V(Typ.1.2V) |
|
|
IOVDD: 1.7~3.0V(Typ.1.8V) |
|
|
Audio frequency |
Optional |
|
Power supply |
USB BUS POWER |
|
Power consumption |
DC 5V, 200mA |
|
Main chip |
DSP/SENSOR/FLASH |
|
Auto Exposure Control (AEC) |
Support |
|
Auto White Balance (AEB) |
Support |
|
Auto Gain Control (AGC) |
Support |
|
Storage temperature |
0~60℃ |
|
Operating temperature |
-20~80℃ |
|
USB cable length |
Default |
|
Support OS |
WinXP/Vista/Win7/Win8/Win10 |
