GC5035 5MP Dual Lens Camera Module Autofocus MIPI
|
Module Number |
SNS51619-V1.1 |
Sensor |
1/5 Inch |
|
Resolution |
5MP 2592(H) X 1944(V) |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Auto Focus |
|
Interface |
MIPI |
Feature |
High-definition |
Products Description
This high-performance 5MP MIPI camera module features a dual-lens configuration and integrates two GalaxyCore 1/5-inch GC5035 CMOS image sensors, each providing 5MP (2592x1944) resolution. Designed for mobile phone cameras and other mobile applications, it delivers enhanced imaging capabilities through an innovative dual-lens solution.
The module supports Auto Focus, allowing each lens to automatically adjust focus to ensure clear and sharp objects at different shooting distances. The dual-lens configuration enhances depth perception and supports advanced imaging effects such as portrait mode (blurred background), improving photo quality and user experience.
High-speed data transmission through a standard MIPI interface seamlessly connects to the camera system of a mobile phone or tablet for efficient and reliable image and video capture. The GC5035 sensor has good dynamic range and light sensitivity to ensure high-quality image output.
The module features a compact design for mobile devices with strict space requirements. The size can be customized to meet your product structure requirements. The camera is equipped with an 80° DFOV M12 lens by default (optional), and can be customized to match any angle.
Highlights
GalaxyCore GC5035 sensor.
Dual Lens Module.
5MP (2592x1944) resolution per lens.
Supports Auto Focus.
Enhanced Depth Sensing.
Specification
|
Model No |
SNS51619-V1.1 |
|
Sensor |
1/5'' inch |
|
Pixel |
5 Mega Pixel |
|
Most effective pixels |
2592(H) x 1944(V) |
|
Pixel Size |
1.2µm x 1.2µm |
|
Resolution & Frame rate |
See above |
|
Shutter Type |
Electronic rolling shutter |
|
Focus type |
Fixed focus |
|
S/N ratio |
36dB |
|
Dynamic range |
72 dB @ 8x gain |
|
Sensitivity |
690mV / lux-sec |
|
Adjustable parameter |
Brightness/Contrast/Color saturation/Hue/Definition/ |
|
Lens |
TTL: 23.89MM |
|
|
Lens Size: 1/3 inch |
|
|
DFOV: 80° |
|
|
Thread Size: M12*P0.5 |
|
Audio frequency |
Optional |
|
Power supply |
USB BUS POWER |
|
Power consumption |
DC 5V, 200mW |
|
Main chip |
DSP/SENSOR/FLASH |
|
Auto Exposure Control (AEC) |
Support |
|
Auto White Balance (AEB) |
Support |
|
Auto Gain Control (AGC) |
Support |
|
Storage temperature |
-20°C to 70°C |
|
Operating temperature |
0°C to 60°C |
|
USB cable length |
Default |
|
Support OS |
WinXP/Vista/Win7/Win8/Win10 |
