Digital CCTV 16MP IMX298 USB Camera Module with HDR Autofocus and Optical Zoom

Digital CCTV 16MP IMX298 USB Camera Module with HDR Autofocus and Optical Zoom

$60.00 | 0 (Min.Order)

Product Details:
Place of Origin: Shenzhen,China
Brand Name: Muchvision
Certification: RoHS、CE、FCC 、ISO9001

Payment & Shipping Terms:
Minimum Order Quantity:3
Price:negotiable
Packaging Details:Tray+Anti-static bag in carton box
Delivery Time:2-3weeks
Payment Terms:T/T
Supply Ability:500000 pieces/month
Send Inquiry
Add To Cart
Description
Technical Parameters

Digital CCTV Camera Module 16MP IMX298



Module Number

SNS-16MP-IMX298-H1

Sensor

1/2.8" SONY IMX298

Resolution

16MP 4608*3456

Dimension

(customizable)

Lens FOV

85°(optional)

Focus Type

Auto Focus (Optical Zoom)

Interface

USB2.0

Feature

HDR



Products Description



The Digital CCTV Camera Module 16MP IMX298 is a professional high-resolution solution powered by the Sony IMX298 CMOS sensor. It outputs 4608x3456 ultra-high-definition images, providing outstanding clarity and fine details required for CCTV monitoring, surveillance, and industrial inspection.



Equipped with autofocus and optical zoom, the module automatically adjusts focal length and viewing angle, ensuring that distant objects can be captured clearly. This capability is critical in security and monitoring scenarios where long-distance detail recognition is essential. The built-in HDR function enhances performance under strong light contrast, ensuring accurate image quality in both bright and dark environments.



Designed for reliability, the module supports customizable housing options, including waterproof steel enclosures for outdoor or harsh environments. Its compact size and flexible lens configurations make it suitable for diverse projects, from smart surveillance systems to industrial machine vision.



Highlights



16MP Resolution: 4608x3456 images with ultra-clear details

Sony IMX298 Sensor: High sensitivity and HDR imaging for accurate details

Autofocus + Optical Zoom: Capture clear images at varying distances

CCTV-Ready Design: Ideal for monitoring, surveillance, and industrial use

Customizable Options: Module size, lens FOV, and waterproof housing available



Specification



Pixel Size

1.12μm x 1.12μm

Effective Pixels

4608*3456

Image Sensor

1/2.8"

Sensor Type

SONY IMX298

Lens View

FOV90°(Optional),F/N(Optional)

TV Distortion

<1% (Optional)

Temperature(Operation)

0~60℃

Temperature(Storage)

-20~70℃

Dimension

Customizable
