5MP DVP OV5647 Camera Module IR 650nm Filter
|
Module Number |
SNS-5MP-OV5647-v1.0 |
Sensor |
1/4" Omnivision OV5647 |
|
Resolution |
5MP 2592(H) X 1944(V) |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Fixed Focus |
|
Interface |
DVP |
Feature |
HD |
Products Description
The SNS-5MP-OV5647-v1.0 is a high-quality DVP camera module built with the Omnivision OV5647 CMOS sensor, capable of producing 5MP (2592x1944) still images and smooth 1080P full HD video at 30FPS.
It features a fixed-focus lens with a 650nm infrared cutoff filter, providing natural color reproduction in daylight applications. To meet diverse requirements, the module supports customization options including autofocus, infrared filters (650nm/850nm/940nm), and flexible FOV choices. With its customizable dimensions and stable DVP interface, this module ensures easy integration into embedded vision systems.
The OV5647's 1.4μm pixel design delivers sharp imaging, while its low power consumption and wide adaptability make it suitable for surveillance, IoT devices, robotics, and consumer electronics.
Highlights
Omnivision OV5647 CMOS image sensor
5MP (2592x1944) high resolution stills
1080P Full HD video @ 30FPS
650nm IR filter with customizable 850nm/940nm options
Specification
|
Pixel Size |
1.4μm x 1.4μm |
|
Effective Pixels |
2592*1944 |
|
Image Sensor |
1/4" |
|
Sensor Type |
OV5647 |
|
Lens View |
FOV85°(Optional),F/N(Optional) |
|
TV Distortion |
<1% (Optional) |
|
Temperature(Operation) |
0~60℃ |
|
Temperature(Storage) |
-20~70℃ |
|
Dimension |
Customizable |
