OV7725 DVP Camera Module Thermal Imaging Module
|
Module Number |
SNS-18964-v1.0 |
Sensor |
1/4" Omnivision OV7725 |
|
Resolution |
0.3MP 640*480 |
Dimension |
(customizable) |
|
Lens FOV |
120°(optional) |
Focus Type |
Fixed Focus |
|
Interface |
DVP |
Feature |
Global Shutter |
Products Description
This high-performance DVP camera module is equipped with an Omnivision 1/4-inch OV7725 CMOS image sensor, offering 0.3MP (640x480) VGA resolution. It features a fixed-focus design, making it particularly suitable for integration into robot vision systems and various embedded applications with strict space requirements.
The module measures just 12.5x19.95mm (customizable), making it extremely compact and easy to deploy in limited spaces. The OV7725 sensor is renowned for its stability and reliability in VGA-level applications, delivering clear images suitable for robot vision recognition and basic image capture. It employs rolling shutter technology.
Highlights
Omnivision OV7725 CMOS sensor.
0.3MP VGA (640x480) resolution.
Ultra-compact size: 12.5x19.95mm (customization available).
DVP interface.
Product structure
Specification
|
Pixel Size |
1.4μm x 1.4μm |
|
Effective Pixels |
640*480 |
|
Image Sensor |
1/4" |
|
Sensor Type |
OV7725 |
|
Lens View |
FOV120°(Optional),F/N(Optional) |
|
TV Distortion |
<1% (Optional) |
|
Temperature(Operation) |
0~60℃ |
|
Temperature(Storage) |
-20~70℃ |
|
Dimension |
12.5*19.95mm (Customizable) |
