OEM dual OV9281 camera module 120fps Main parameters
|
Module Number |
SNS-SM1159-V1.0 |
Sensor |
OV9281 |
|
Resolution |
1mp 720p |
Dimension |
Customizable |
|
Lens FOV |
83 (Optional) |
Focus Type |
Fixed Focus |
|
Interface |
USB2.0 |
Feature |
Dual lenses |
Products Description
The core advantage of the SNS-SM1159-V1.0 module is its 1/4 inch CMOS sensor with an effective pixel size of 1280x800 and a pixel size of 3.0μm x 3.0μm, providing high definition and accurate color capture capabilities.
The module realizes 480MB/s high-speed data transmission through USB 2.0 interface, which ensures the instant processing of image data. JPG, BMP static image and AVI, MP4 dynamic video capture, providing users with a wide range of application flexibility. Image enhancement features in hardware and underlying software, including exposure, chromatic aberration, brightness, contrast, and saturation adjustment, make post-processing more efficient.
The operating temperature range of the module is -10°C to 60°C, and the storage temperature range is -20°C to 70°C, ensuring stable operation in a variety of environments. Plug and play USB 2.0 interface without external power supply.
Feature
High resolution: 1280x800 effective pixels for sharp image detail.
Excellent low light performance: Image quality is maintained even in low light conditions.
Multi-format support: JPG, BMP, AVI, MP4 and other image and video formats are supported.
Image enhancement function: Hardware and software support a variety of image adjustment, optimize post-processing.
System compatibility: Supports Windows, Linux, Mac, and Android operating systems.
Product structure
Specification
Overall performance parameters
|
Signal |
SNS-SM1159-V1.0 |
REMARKS |
|
|
Image Sensor Size |
1/4 inch |
||
|
Effective Pixels |
1280H*800V |
|
|
|
Pixel size |
3 um*3 um |
|
|
|
Optical distortion |
<-1.2% |
|
|
|
Image sensor Data output |
Raw Bayer 10bits |
|
|
|
Video output |
MPJG/YUV |
|
|
|
Maximum Frame Rates |
2560*800 120FPS 1280*800 120FPS 1280*792 120FPS 2560*720 120FPS 1280*720 120FPS 1280*712 120FPS 1600*600 120FPS 800*600 120FPS 800*592 120FPS 1280*480 210FPS 640*472 210FPS 1280*400 210FPS 640*400 210FPS 640*392 210FPS 640*480 210FPS 640*240 210FPS 320*240 210FPS 320*232 210FPS |
MPJG |
|
|
SNR max |
TBD |
|
|
|
Dynamic range |
TBD |
|
|
|
Min. Illumination |
TBD |
||
|
Digital interface |
USB2.0 |
Cable length 1.5 meters |
|
|
Transfer rates |
480MB/S |
|
|
|
Power requirements |
5V±5% |
|
|
|
Storage temperature |
-20℃to70℃ |
|
|
|
operating temperature |
-10℃to60℃ |
|
|
|
Power Consumption |
NO LED |
/ |
|
|
IR-LED |
/ |
|
|
|
PCB printig ink |
black |
||
|
OS |
Windows XP /vista/seven/8.1/10/Mac /Android/linux2.6.2(include UVC ) |
|
|
|
Lens view |
M12*P0.5 |
LENS |
|
|
Lens Construction |
1G5P+650IR |
|
|
|
F/NO |
2.4±5% |
|
|
|
EFL |
2.6 mm±5% |
|
|
|
FOV |
D ：83°±3° |
|
|
|
Focusing method |
Fixed focus |
|
|
|
Shooting distance |
60cm-∞ |
|
|
Product Picture
Application areas of camera modules
1. Astrophotography: Used in astrophotography to capture high definition images of starry skies and celestial bodies
2. Microscope camera: Integrated with a microscope to capture high definition images of the microscopic world for research and education
3. Traffic monitoring: Used for traffic monitoring, monitoring traffic flow and road safety, reducing traffic accidents
