1080P USB 2MP C2496 CMOS Camera Module
|
Module Number |
SNS-C2496 |
Sensor |
C2496 |
|
Resolution |
2.2 μm (H) * 2.2 μm (V) |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Fixed Focus |
|
Interface |
USB2.0 |
Feature |
HD |
Products Description
The C2496 2MP 1080P USB2.0 camera module provides high-definition imaging for surveillance and industrial applications. Featuring an integrated ISP on the chip and a back-illuminated (BSI) sensor, it delivers clear, low-noise images even in low-light conditions.
The module outputs stable 1080P video at 30 frames per second, with reduced fixed pattern noise for improved image clarity. Programmable control allows developers to adjust brightness, contrast, and other image parameters for flexible integration.
Compact and easy to deploy, the module connects via USB2.0 and is ideal for security monitoring, industrial inspection, and other applications requiring reliable high-definition imaging.
Highlights
Integrated ISP: Optimized image processing on-chip for high-quality output
Excellent low-light performance: BSI sensor reduces noise and improves sensitivity
1080P 30FPS output: Smooth and stable video for surveillance and industrial use
Programmable controls: Developers can adjust multiple image parameters
Fixed-focus lens: Simplifies installation and ensures consistent imaging
Compact and flexible design: Easy integration with USB2.0 connectivity
Specification
|
Optical Format |
1/3.7-inch |
|
|
Active Pixel Array(1080P) |
1936H×1096V |
|
|
Pixel Size |
2.2 μm (H) × 2.2 μm (V) |
|
|
Color Filter Array |
RGB Bayer Pattem |
|
|
Chief Ray Angle |
9° linear |
|
|
Shutter Type |
Electronic Rolling Shutter |
|
|
Maximum Frame Rate |
1080p:30fps |
|
|
Power supply |
AVDD |
3.0~3.6V(3.3V nominal) |
|
I/O |
1.7~AVDD(1.8V nominal) |
|
|
DVDD |
1.08~1.32V(1.2V nominal) |
|
|
Power Consumption |
Active |
105mW |
|
XSutdown |
<1µA |
|
|
Output Formats |
10-bit RAW |
|
|
Operating Temperature |
-30ºC to 85ºC |
|
|
Storage Temperature |
--40ºC to 95ºC |
|
|
Die Dimensions ( μm2) |
5,210×3,640 |
|
