IMX307 2MP USB 3.0 Camera Module 1080P 30FPS For Face Recognition
|
Module Number |
SNS-GM307-V1.0 |
Sensor |
1/2.8" SONY IMX307 |
|
Resolution |
1945 (H) X 1097 (V) |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Fixed Focus |
|
Interface |
USB3.0 |
Feature |
HD |
Products Description
This IMX307 USB 3.0 camera module uses Sony's Starvis IMX307 sensor. The most outstanding feature of this sensor is its low-light shooting ability - it can obtain clear images even in low light conditions. At the same time, it can reach a frame rate of 60 frames per second and provide clear 1080p (1920x1080) video, which is very suitable for applications that require smooth images, such as face recognition or surveillance.
This USB 3.0 camera module is easy to connect and supports multiple compression formats, including H.264, which effectively saves bandwidth. The wide 130° viewing angle allows you to image a wider range, and you can also choose fixed focus or manual focus. It is worth noting that if you can manually adjust the brightness and exposure, the image quality will be further improved.
Highlights
Excellent low-light vision: Sony Starvis technology allows for clear viewing even in low-light environments.
High-speed 60FPS: Provides smooth 1080p video.
USB 3.0 interface: Provides high-speed data transfer.
130° wide viewing angle: Capture a wider scene.
Support H.264: Save bandwidth for efficient streaming.
Product Structure
Specification
|
Model No |
SNS-GM307-V1.0 |
|
Sensor |
1/2.8'' SONY IMX307 CMOS |
|
Pixel |
2 Mega Pixel |
|
Most effective pixels |
1920(H) x 1080(V) |
|
Pixel Size |
2.9µm x 2.9µm |
|
Image area |
1937(H) x 1097(V) |
|
Compression format |
MJPEG / YUV2/H.264 |
|
Resolution & Frame rate |
1920 x1080 @ 60fps 1280x960 @60fps 1280x720 @ 60fps 800x600 @ 60fps 640x480 @ 60 fps 320x240 @ 60fps |
|
Shutter Type |
Electronic rolling shutter |
|
Focus type |
Fixed focus/Manually adjustable |
|
Sensitivity |
7757 mV / lux-sec |
|
Interface type |
USB2.0 and SPI |
|
Adjustable parameter |
Brightness |
|
Lens |
Optical length: 18.6mm |
|
F/NO: 2.4 |
|
|
FOV: D=130° |
|
|
Thread Size: M12*P0.5 |
|
|
Audio frequency |
Optional |
|
Power supply |
USB BUS POWER |
|
Power consumption |
DC 5V, 260mW |
|
Main chip |
DSP/SENSOR/FLASH |
|
Auto Exposure Control (AEC) |
NOT Support |
|
Auto White Balance (AEB) |
NOT Support |
|
Auto Gain Control (AGC) |
NOT Support |
|
Dimension |
32mm x 32mm |
|
Storage temperature |
-40 ─ 85 ˚C |
|
Operating temperature |
-30 ─ 85 ˚C |
|
USB cable length |
Default |
|
Support OS |
WinXP/Vista/Win7/Win8/Win10 |
