13MP Autofocus IMX258 USB Camera Module High Resolution HD Imaging for Versatile Applications

13MP Autofocus IMX258 USB Camera Module High Resolution HD Imaging for Versatile Applications

$60.00 | 0 (Min.Order)

Product Details:
Place of Origin: Shenzhen,China
Brand Name: Muchvision
Certification: RoHS、CE、FCC 、ISO9001

Payment & Shipping Terms:
Minimum Order Quantity:3
Price:negotiable
Packaging Details:Tray+Anti-static bag in carton box
Delivery Time:2-3weeks
Payment Terms:T/T
Supply Ability:500000 pieces/month
Send Inquiry
Add To Cart
Description
Technical Parameters

13MP Autofocus IMX258 Camera Module USB



Module Number

HSJ80-GM258FD-V1.0

Sensor

1/3.06" SONY IMX258

Resolution

13MP 4224 (H) * 3144 (V)

Dimension

(customizable)

Lens FOV

85°(optional)

Focus Type

Autofocus

Interface

USB2.0

Feature

HD



Products Description



The 13MP Autofocus IMX258 USB Camera Module is designed for high-definition imaging in applications where clarity and precision are critical. Powered by the SONY IMX258 sensor, it delivers 4224x3144 resolution images with excellent detail and color accuracy.



A key advantage of this module is its autofocus function, which automatically adjusts to the subject distance. Whether the scene involves moving objects or varying depths of field, the camera ensures consistently sharp results. This makes it suitable for inspection, video conferencing, document capture, and AI vision systems.



Integration is simple with the USB2.0 plug-and-play interface, compatible with Windows, Linux, macOS, and Android platforms. The module also supports customizable dimensions and optional lens FOV, allowing flexibility for integration into different hardware designs.



Highlights



13MP High Resolution: Capture 4224x3144 pixel images with rich detail

SONY IMX258 Sensor: Ensures sharp and high-quality imaging performance

Autofocus Function: Automatically adapts to subject distance for clear results

USB2.0 Interface: Plug-and-play setup with wide system compatibility

Customizable Design: Flexible dimensions and lens options for integration



Specification



Pixel Size

1.12 μm (H) × 1.12 μm (V)

Effective Pixels

4224 (H) × 3144 (V)

Image Sensor

1/3.06

Sensor Type

IMX258

Operating temperature

-20 to ~70 ˚C

Storage temperature

-30 to ~80 ˚C

Lens view

FOV80°(optional),F/N(optional)

TV Distortion

<1%

Operating voltage

AVDD:3.0~3.6V DOVDD:1.7~3.6V DVDD:1.7~1.9V

Dimensions

Customizable
