Low Light Performance OV13850 13MP Camera Module
|
Module Number |
SNS-131128-V1.1 |
Sensor |
Omnivision OV13850 |
|
Resolution |
13MP 4224(H) X 3136(V) |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Auto Focus |
|
Interface |
MIPI |
Feature |
Low Light Performance |
Products Description
The OV13850 13MP MIPI Camera Module is a high-performance imaging solution for smartphones and tablets, featuring the OmniVision OV13850 PureCel™ sensor. It captures 4224x3136 HD images with excellent low-light performance while significantly reducing power consumption by 40% compared to previous generations.
The module supports autofocus and zero shutter lag for quick and sharp image capture. Video capabilities include 4K2K UHD at 30FPS and 1080P HD at 60FPS, both with EIS (Electronic Image Stabilization) to ensure smooth and clear video output. Compact and customizable, it is ideal for mobile devices that prioritize image quality, energy efficiency, and high-performance video capture.
Highlights
13MP HD resolution: 4224x3136 pixel images with rich detail
OmniVision OV13850 PureCel™ sensor: excellent low-light sensitivity
Low-power design: 40% lower power consumption than previous generation
High-quality video: 4K2K@30FPS and 1080P@60FPS with EIS
Autofocus and zero shutter delay: fast and precise image capture
Customizable size and lens: flexible integration for mobile devices
Specification
|
Module No |
SNS-113128-V1.1 |
|
Pixel Size |
3.75μm x 3.75μm |
|
Effective Pixels |
13MP 4224(H) x 3136(V) |
|
Video output |
Raw Bayer10bit/8bit |
|
Active Array Size Video Rate |
Full resolution@30FPS,1080P@60FPS |
|
Sensor Type |
Omnivision OV13850 |
|
Lens view |
FOV90°(optional),F/N(optional) |
|
TV Distortion |
<1% |
|
AEC |
Support |
|
AEB |
Support |
|
AGC |
Support |
|
Operating voltage |
AVDD:3.0~3.6V DOVDD:1.7~3.6V DVDD:1.7~1.9V |
|
Operating temperature |
0～60℃ |
|
Storage temperature |
-20～70℃ |
|
Dimensions |
Customizable |
