Samsung S5K3L2 13MP Camera Module For Mobile Phone
|
Module Number |
SNS-131168-V1.0 |
Sensor |
Samsung S5K3L2 |
|
Resolution |
13MP 4208(H) X 3120(V) |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Auto Focus |
|
Interface |
MIPI |
Feature |
Low Light Performance |
Products Description
This 8MP USB camera module uses the SONY IMX317 sensor. It delivers 3840×2160 4K resolution. The module supports 30FPS at full resolution.
The fixed focus design ensures stable and clear images. Its compact design allows flexible integration into small devices.
The USB2.0 interface provides plug-and-play connectivity. It is suitable for video conferencing, drones, IoT devices, and embedded vision systems. Firmware optimization ensures consistent image quality.
Highlights
8MP 4K UHD: 3840×2160 resolution at 30FPS
Fixed focus: stable and clear images
Compact design: easy integration into small devices
USB2.0 interface: plug-and-play, wide compatibility
Specification
|
Module No |
SNS-113128-V1.1 |
|
Pixel Size |
3.75μm x 3.75μm |
|
Effective Pixels |
13MP 4208(H) x 3120(V) |
|
Video output |
Raw Bayer10bit/8bit |
|
Active Array Size Video Rate |
Full resolution@30FPS,1080P@60FPS |
|
Sensor Type |
Samsung S5K3L2 |
|
Lens view |
FOV90°(optional),F/N(optional) |
|
TV Distortion |
<1% |
|
AEC |
Support |
|
AEB |
Support |
|
AGC |
Support |
|
Operating voltage |
AVDD:3.0~3.6V DOVDD:1.7~3.6V DVDD:1.7~1.9V |
|
Operating temperature |
0～60℃ |
|
Storage temperature |
-20～70℃ |
|
Dimensions |
Customizable |
