Custom 2MP 1920x1080P USB GC2053 Camera Module
|
Module Number |
SNS-GC2053-V1.0 |
Sensor |
1/2.9'GC2053 CMOS |
|
Resolution |
1920(H) X 1080(V) |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Fixed Focus |
|
Interface |
USB2.0 |
Feature |
HDR |
Products Description
The GC2053 2MP 1080P USB2.0 camera module is a versatile HD imaging solution optimized for surveillance, recognition, and embedded applications. Equipped with a 1/2.9" GC2053 CMOS sensor and a distortion-free lens, it delivers clear 1080P images with accurate color reproduction and good performance in low-light environments.
This module supports dual frame rate output: HD mode at 1080P@30FPS for full-resolution clarity, and smooth mode at 720P@60FPS for dynamic scenarios requiring fluid motion. The standard USB2.0 interface ensures plug-and-play integration and compatibility across Windows, Linux, macOS, and Android platforms.
With a fixed-focus lens and customizable dimensions, it can be easily integrated into dashcams, webcams, video conferencing systems, and other embedded devices. Programmable parameters such as brightness, contrast, color saturation, hue, gamma, white balance, and exposure allow fine-tuning for specific application requirements.
Highlights
Dual frame rate output: HD 1080P@30FPS for clarity and 720P@60FPS for smooth motion
Distortion-free lens: Ensures accurate and realistic imaging
USB2.0 plug-and-play: Supports mainstream operating systems for easy integration
Fixed-focus design: Simplifies installation while maintaining stable image quality
Low-light adaptability: Provides clear imaging even in challenging lighting conditions
Specification
|
Model No |
SNS-GC2053-V1.0 |
|
Sensor |
1/2.9'GC2053 CMOS |
|
Pixel |
2 Mega Pixel |
|
Most effective pixels |
1920(H) x 1080(V) |
|
Pixel Size |
2.8um x2.8um |
|
Image Area |
5808µm x 3288µm |
|
Compression format |
YUV2 / MJPG |
|
Resolution |
See above |
|
Frame rate |
See above |
|
Shutter Type |
Electronic rolling shutter |
|
Focus type |
Fixed focus |
|
S/N ratio |
TBDdB |
|
Dynamic range |
TBDdB |
|
Sensitivity |
3700 mV/lux-sec |
|
Interface type |
USB2.0 |
|
|
Brightness/Contrast/Color saturation/Hue/Definition/ |
|
Power supply requirement |
AVDD28: 2.7~3.3V(Typ.2.8V) |
|
DVDD18: 1.15~1.3V(Typ.1.2V) |
|
|
IOVDD: 1.7~3.0V(Typ.1.8V) |
|
|
Audio frequency |
Optional |
|
Power supply |
USB BUS POWER |
|
Power consumption |
DC 5V, 200mA |
|
Main chip |
DSP/SENSOR/FLASH |
|
Auto Exposure Control (AEC) |
Support |
|
Auto White Balance (AEB) |
Support |
|
Auto Gain Control (AGC) |
Support |
|
Storage temperature |
0~60℃ |
|
Operating temperature |
-20~80℃ |
|
USB cable length |
Default |
|
Support OS |
WinXP/Vista/Win7/Win8/Win10 |
