1080P GC2053 2MP Camera Module 30fps
|
Module Number |
SNS-G2053-V1 |
Sensor |
1/2.9'GC2053 CMOS |
|
Resolution |
1920(H) X 1080(V) |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Fixed Focus |
|
Interface |
MIPI |
Feature |
HDR,Electronic Rolling Shutter |
Products Description
The GC2053 2MP 1080P USB2.0 camera module provides high-quality imaging for automotive and security monitoring applications. Equipped with a 1/2.9" GC2053 CMOS sensor, it delivers Full HD 1080P video with electronic rolling shutter and HDR/WDR support, ensuring details are preserved in high-contrast scenes such as vehicles entering tunnels or under bright sunlight.
The module maintains clear and stable imaging even in low-light or nighttime conditions. Its fixed-focus lens, USB2.0 interface, and low power consumption make integration easy while extending battery life in dash cams and mobile applications. Operating reliably in temperatures from -20°C to 80°C, the module is ideal for demanding environments requiring robust performance and high image quality.
Highlights
Wide Dynamic Range (WDR) and HDR: Preserves details in high-contrast lighting
Stable imaging in harsh environments: Performs reliably under extreme temperatures and low light
Low power consumption: Balances performance and battery life for mobile applications
1080P Full HD output: Clear and detailed video at 30FPS
USB2.0 interface: Easy plug-and-play integration
Fixed-focus lens: Simplifies installation and ensures consistent imaging
Product Structure
Specification
|
Model No |
SNS-G2053-V1 |
|
Sensor |
1/2.9'GC2053 CMOS |
|
Pixel |
2 Mega Pixel |
|
Most effective pixels |
1920(H) x 1080(V) |
|
Pixel Size |
2.8um x2.8um |
|
Image Area |
5808µm x 3288µm |
|
Compression format |
YUV2 / MJPG |
|
Resolution |
See above |
|
Frame rate |
See above |
|
Shutter Type |
Electronic rolling shutter |
|
Focus type |
Fixed focus |
|
S/N ratio |
TBDdB |
|
Dynamic range |
TBDdB |
|
Sensitivity |
3700 mV/lux-sec |
|
Interface type |
USB2.0 |
|
Adjustable parameter |
Brightness/Contrast/Color saturation/Hue/Definition/ |
|
Power supply requirement |
AVDD28: 2.7~3.3V(Typ.2.8V) |
|
DVDD18: 1.15~1.3V(Typ.1.2V) |
|
|
IOVDD: 1.7~3.0V(Typ.1.8V) |
|
|
Audio frequency |
Optional |
|
Power supply |
USB BUS POWER |
|
Power consumption |
DC 5V, 200mA |
|
Main chip |
DSP/SENSOR/FLASH |
|
Auto Exposure Control (AEC) |
Support |
|
Auto White Balance (AEB) |
Support |
|
Auto Gain Control (AGC) |
Support |
|
Storage temperature |
0~60℃ |
|
Operating temperature |
-20~80℃ |
|
USB cable length |
Default |
|
Support OS |
WinXP/Vista/Win7/Win8/Win10 |
