MJPEG Low Power USB Camera Module OV2735 30FPS
|
Module Number |
SNS-WK2735-V1.0 |
Sensor |
1/2.7" Omnivision OV2735 |
|
Resolution |
2MP 1920x1080 |
Dimension |
(customizable) |
|
Lens FOV |
85°(optional) |
Focus Type |
Fixed Focus |
|
Interface |
USB2.0 |
Feature |
HD |
Products Description
The OV2735 2MP 1080P USB2.0 camera module offers high-definition imaging optimized for low-power applications such as dashcams and portable devices. Equipped with a 1/2.7" Omnivision OV2735 sensor, it delivers stable Full HD 1080P video at 30 frames per second using MJPEG compression.
Low-power mode reduces energy consumption while maintaining consistent image quality. Programmable parameters including gain, exposure, frame rate, image size, mirror, and flip provide flexibility for diverse application needs. The fixed-focus lens design simplifies installation and ensures consistent imaging performance.
With USB2.0 connectivity, the module supports plug-and-play integration across Windows, Linux, macOS, Android, and other platforms, making it ideal for automotive, mobile, and industrial HD imaging applications.
Highlights
Low-power operation: Reduces energy consumption for battery-powered or power-sensitive devices
1080P 30FPS HD video: Provides stable and clear Full HD imaging for dashcams and portable systems
Programmable parameters: Adjustable gain, exposure, frame rate, and image settings for custom applications
Fixed-focus lens: Simplifies installation and maintains consistent image quality
USB2.0 interface: Easy plug-and-play integration across multiple platforms
Versatile applications: Suitable for automotive, mobile, and industrial HD imaging
Specification
|
Module No |
SNS-WK2735-V1.0 |
|
Pixel Size |
3.0μm x 3.0μm |
|
Effective Pixels |
1920(H)X1080(V) |
|
Video output |
YUV2 MJPG |
|
Active Array Size Video Rate |
1080p@30FPS |
|
Image Sensor |
1/2.7" OV2735 |
|
SNR max |
TBDdB |
|
Dynamic range |
TBDdB |
|
OTG |
USB2.0 OTG |
|
AEC |
Support |
|
AEB |
Support |
|
AGC |
Support |
|
Adjustable parameter |
Brightness/Contrast/Color saturation/Hue/Definition/Gamma/White balance/Exposure |
|
Lens view |
FOV:D97° H83°V56°F/N(2.0) |
|
Interface |
USB BUS POWER 5P-1.25mm |
|
Operating Voltage |
DC5V |
|
Operating Current |
MAX120MMA |
|
Operating temperature |
0～60℃ |
|
Storage temperature |
-20～80℃ |
|
Cable length |
Defualt |
|
OS |
WinXP/Vista/Win7/Win8 Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later Wince with UVC Android 4.0 or above with UVC |
